Rangemaster Classic Series - Cooker overview; Hotplate burners

7
The 90 dual fuel cooker (Fig. 2.1) has the following features:
A. 5 hotplate burners including a wok burner
B. Control panel
C. Glide-out Grill™
D. A main programmable fan oven
E. Tall fan oven
Hotplate burners
The drawing by each of the central knobs indicates which
burner that knob controls.
Each burner has a Flame Supervision Device (FSD) that
prevents the ow of gas if the ame goes out.
When the igniter button (or the control knob on the
Classic Deluxe) is pressed in, sparks will be made at every
burner – this is normal. DO NOT attempt to disassemble
or clean around any burner while another burner is on,
otherwise an electric shock could result.
To light a burner, press the igniter button, and push in and
turn the associated control knob to the high position as
indicated by the large ame symbol (

), (Fig. 2.2).
NOTE: On the Classic Deluxe, simply push in and turn the
control knob.
M
+
-
C
B
D
A
E
2. Cooker overview
Fig. 2.1
Fig. 2.2
