Rapid Engineering 2000 Series - Page 77

SECTION 20: START-UP P ROCEDURES
71
FIGURE 35: M611 Valve
FIGURE 36: Regulator (2005)
Low Fire Adjustment
(under cap)
Gas Inlet
Gas Outlet
NOTE: Modulating only.
IN
PSI
2
OFF
ON
Outlet Pressure
Tap-1/8 NPT
Inlet Pressure
Tap-1/8 NPT
Regulator
Adjustment Below
(High Fire Adjustment Cap)
Gas FlowGas Flow
