Thank you for purchasing RATH’s SmartRescue Base Station. We are the largest Emergency Communication
Manufacturer in North America and have been in business for over 35 years.
We take great pride in our products, service, and support. Our Emergency Products are of the highest quality.
Our experienced customer support teams are available to remotely assist with site preparation, installation,
and maintenance. It is our sincere hope that your experience with us has and will continue to surpass your
expectations.
Thank you for your business,
®
N56W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 www.rathcommunications.com
Table of Contents
SmartRescue 5 & 10 Installation . . . . . . . . . . . . . . . .
Powering the SmartRescue . . . . . . . . . . . . . . . . . . . .
Wiring Emergency Phones to SmartRescue . . . . . .
Typical Wiring Diagrams for Elevators . . . . . . . . . . .
Typical Wiring Diagram for Areas of Refuge . . . . . .
Programming Options . . . . . . . . . . . . . . . . . . . . . . . .
Operations & Testing the System . . . . . . . . . . . . . . .
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Machine Room Phone Installation & Operation . . .
SmartRescue System Activation Relay . . . . . . . . . .
Programming Phones into Consolidator Mode . . . .
Adjusting Volume on SmartPhones . . . . . . . . . . . . .
Change Frequency of Phone Line Check . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SmartRescue Specications . . . . . . . . . . . . . . . . . . .
Models & Dierences . . . . . . . . . . . . . . . . . . . . . . . . .
SmartRescue Drawings . . . . . . . . . . . . . . . . . . . . . . .
Page 3
Page 4
Page 5
Pages 6-7
Page 8
Pages 8-9
Pages 9-10
Page 10
Page 11
Page 11
Pages 11-12
Page 12
Page 12
Page 12
Page 13
Page 13
Pages 14-15
Conforms to UL Standard 2017 for Attendant Monitored Signaling Devices
Complies with Section 6.4 of UL 60950-1
ETL Listing Number: 5013373
