Typical Wiring Diagrams for Elevator Applications
Connect 24vac or 24vdc from power source to power wiring harness on phone.
The power connection is not polarity sensitive.
Page 6
Hard-Wired Transformer:
0
2
5
3
1
4 6
7
8 9
*
#
0
2
5
3
1
4 6
7
8 9
*
#
0
2
5
3
1
4 6
7
8 9
*
#
0
2
5
3
1
4 6
7
8 9
*
#
0
2
5
3
1
4 6
7
8 9
*
#
2 Pair- Twisted
24-22ga
2 Pair- Twisted
24-22ga
2 Pair- Twisted
24-22ga
2 Pair- Twisted
24-22ga
2 Pair- Twisted
24-22ga
1 Pair Wire
From Telco
GROUND
NEUTRAL
120vac
HOT
SUB-MASTER 1
SUB-MASTER 2
OPERATION:
1. SOLID LIT LED (PHONE, SUB-MASTER
OR RESCUE SERVICES) INDICATES
CALL IN PROGRESS.
2. SLOW BLINKING LED INDICATES
CALL ON HOLD.
3. LIFT HANDSET.
4. PRESS YELLOW TALK/HOLD BUTTON TO CALL
IN TO A SPECIFIC SUB-MASTER. IF THE GREEN
LED IS LIT YOU WILL JOIN CONVERSATION.
5. PRESS BLACK TALK/HOLD BUTTON TO CALL IN
TO A SPECIFIC PHONE. IF THE GREEN LED IS
LIT YOU WILL JOIN CONVERSATION.
6. PRESS TALK/HOLD BUTTON AGAIN TO PLACE
CONVERSATION ON HOLD.
7. PRESS RED DISCONNECT CALL TO RESCUE
SERVICES BUTTON TO END EXTERNAL CALL.
ANY PHONE AND SUB-MASTER ORIGINALLY
TALKING REMAIN IN CONVERSATION WITH
THIS UNIT.
8. HANG UP HANDSET TO END CALLS TO PHONE
AND SUB-MASTER.
BATTERY
POWER
PHONE 1
PHONE 2
PHONE 3
PHONE 4
PHONE 5
DISCONNECT
CALL TO
RESCUE
SERVICES
SMARTRESCUE PHONE - 5
READ ALL OPERATING STEPS
BEFORE PROCEEDING
RESCUE SERVICES
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
EMERGENCY PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
EMERGENCY PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
EMERGENCY PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
EMERGENCY PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
EMERGENCY PHONE
24v
24v
24v
24v
24v
L N -V +V
Wiring Diagram with Individual Transformers
N56W24720 N. Corporate Circle • Sussex, WI 53089
800-451-1460 • www.rathcommunications.com
02/22
Twisted, Shielded
Wire Recommended
To Next Page
