6.6 Indicator functions
Display Functions
the weighing system (including load) is stable
the weight shown is negative
ZERO the weight shown is within the zero range
NET the display is showing the net weight
e1 displayed weight shown is in range 1 (option multi range)
e2 displayed weight shown is in range 2 (option multi range)
e2 displayed weight shown is in range 3 (option multi range)
F1 Fork 1 / setpoint 1 is activated ( option relay output)
F2 Fork 2 / setpoint 2 is activated ( option relay output)
kg displayed shows weight is kilograms
lb displayed shows weight is pounds
pcs number displayed represent number of pieces on the scale
low bat indicator
