SPECIFICATIONS
CR7 CR12
Connections
• 2 ISOBUS Channels
• 3 Serial Channels
• 1 USB 2.0 Port
• 1 Gigabit Ethernet Port
• 1 Wi-Fi 802.11 b/g/n
• Bluetooth 2.1 with EDR and
BLE 4.0
• 1 Radar Speed Output
• 2 Digital Sense Inputs
• 2 USB 2.0 ports
• 4 ISOBUS 2.0 Compatible
Ports
• 5 RS232 Series Data Ports
(GPS Out, GPS In, Console,
Auxiliary, RTK)
Display
• 7” Widescreen
• Capacitive Touch
• 480 x 800 Resolution
• Screen Brightness 850 NITS
• Integrated Lightbar
• 12” Widescreen
• Capacitive Touch
• 1024 x 768 Resolution
• Screen Brightness 850 NITS
Computing
• 8 GB Storage
•1 GB RAM
• 852 MHz Quad Core
Processor
• 30 GB Internal Storage
•1 GB RAM
•Quad Core Cortex A9
Processor
Power
• 7 to 16 VDC Input
• 850 mA Typical
• Supply Power Fuse: 5 Amp
MINI
®
Fuse
• Keyed Power Start-Up and
Shut-Down
• 4 to 35 VDC Input
Mechanical
• 7.5” x 5.6” x 3.0”
(19 cm x 14.25 cm x 7.62 cm)
• Weight: 1.4 lbs (0.64 kg)
• 1” RAM Ball Mount
• 9.63” x 12.02” x 1.79”
(24.46 cm x 30.53 cm x 4.55
cm)
• Weight: 4.7 lbs (2.13 kg)
•2” RAM Ball Mount
Environmental
• Operating Temperature
Range: -20°C to 70°C
• Storage Temperature Range:
-40°C to 70°C
• IP65 Moisture Protection
• Operating Altitude: 2000m
Maximum
• Operating Temperature
Range: -20°C to 70°C
• Storage Temperature Range:
-40°C to 85°C
• IP65 Moisture Protection
