CHAPTER 2
8 Miller Nitro 5000 Series & New Holland Guardian F Series RS1™ HDU Guidance and Steering Installation Manual
KIT CONTENTS
This section contains a list of the components that are included in the RS1 HDU kit. Before beginning the system
installation, compare the items in the kit with the components on this list. If you have questions about the kit,
contact your Raven dealer.
At Raven Industries, we strive to make your experience with our products as rewarding as
possible. One way to improve this experience is to provide us with feedback on this manual.
Your feedback will help shape the future of our product documentation and the overall service we
provide. We appreciate the opportunity to see ourselves as our customers see us and are eager
to gather ideas on how we have been helping or how we can do better.
To serve you best, please send an email with the following information to
techwriting@ravenind.com
-Miller Nitro 5000 Series & New Holland Guardian F Series RS1™ HDU Guidance and Steering
Installation Manual
-P/N 016-5032-114 Rev. A
-Any comments or feedback (include chapter or page numbers if applicable).
-Let us know how long have you been using this or other Raven products.
We will not share your email or any information you provide with anyone else. Your feedback is
valued and extremely important to us.
Thank you for your time.
TABLE 1.
RS1 HD Installation Kit (P/N 117-5032-114)
Item Description Part Number Qty.
Sheet - Help/Warranty 016-0171-649 1
ECU - Hydraulic Drive Unit (HDU) 063-0173-887 1
Valve - Steering 334-0003-088 1
Bracket - Rotary Sensor Mounting 107-0171-945 1
Bracket - HDU Mounting 107-0172-543 1
