Chapter
6
6.
Connect
the
two
4-pin
Deutsch
connector
from
the
DirecSteer
main
cable
(P/N
115-
8000-474)
to
the
mating
CAN
2
connectors
on
the
SC1™
in-cab
harness
(P/N
115-
8000-475).
7.
Locate
an
open
or
free
console
cavity
for
the
road
switch
and
remove
the
blank.
8.
Route
the
road
switch
connector
from
the
DirecSteer
main
cable
(P/N
115-8000-474)
through
the
open
cavity
and
connect
it
to
the
road
switch.
Note:
Use
the
provided
adapter
for
the
switch
if
needed.
64
69
71
