P/N 016-5032-114 Rev. A
31
CAB COMPONENT INSTALLATION
FIGURE 9.
HDU Harness Bulkhead Connect
or Connected to Machine’s Bulkhead
3.
Connect the CAN/PWR connector of
the HDU harness t
o the machi
ne’
s
bulkhead co
nnector labeled AR0
64.
FIGURE 10.
HDU Harness Connectors Connected to HDU
4.
Install the tw
o rectang
ular connect
ors of the
HDU harness in
t
o the mating ports of the
HDU (P/N 063-0173-
887).
FIGURE 11.
CAN Connection
34
36
