14
CONSOLE PROGRAMMING
When entering data into the Console, the entry sequence is always the same.
NOTE: DATA MUST BE ENTERED FOR ALL BOOMS. ENTER "0" IF BOOM IS NOT
USED. DATA MUST ALSO BE ENTERED IN KEYS 3 THRU 8.
Depress the key in which
you wish to enter data.
Depress the ENTER key. An "E"
will illuminate in the display.
Depress the keys corresponding to
the number you wish to enter (i.e.
"2","1","2", "3"). The numbers will
be displayed as they are entered.
Complete the entry by again de-
pressing the ENTER key.
1. INITIAL CONSOLE PROGRAMMING
When Console power is turned on, after all installation procedures have been completed, the
Console will flash CAL and US VOLUME PER ACRE. This means the console must be
"calibrated", or programmed, before it can be operated. This is a one-time operation which does
not have to be repeated. Turning OFF the POWER ON/OFF switch does not affect the Console
memory. All data is retained.
