Raven SCS 460 Installation Manual

CHAPTER
2
INSTALLATION
___________________________________________________________
Use the following procedure to properly install the CAN AccuBoom
Serial Console cable:
1. Connect the CAN AccuBoom/Serial Console Cable P/N 115-1001-003
to the Raven console.
Important! The CAN AccuBoom/Serial
Console Cable P/N 115-1001-003 is
compatible with Raven SCS440,
SCS450, SCS460, SCS660, and SCS661
consoles only.
a. Disconnect the existing console cable from the back of the console.
Manual #016-0171-073 Rev. C 01/17
3
