Raven SCS 700 User Manual

62
APPENDIX 16
SCS 700/710 COMMUNICATION STRINGS
REMOTE COMPUTER TO SCS 700/710 CONSOLE
All request strings begin with $R, to indicate a Raven communication string.
Rate Change Request:
To set Prod Cal values for both products:
$R,RC,<prod_1_cal>,<prod_2_cal><CR><LF>
To set Prod Cal value for product 2 only:
$R,RC,,<prod_2_cal><CR><LF>
Calibration String Values Request:
$R,CR<CR><LF>
Data String Request:
$R,DR<CR><LF>
SCS 700/710 CONSOLE TO REMOTE COMPUTER
All console output strings begin with $R047F, the $R indicates a Raven communication string, the 047 is
the last three digits of the current SCS 700/710 programmed chip part number and F is the software revision
number.
Calibration Strings:
$R047F,C1,<switch_byte_1>,<switch_byte_2>,
<boom_1_cal>,<boom_2_cal>,<boom_3_cal>,<boom_4_cal>*,
<boom_5_cal>*,<boom_6_cal>*,<speed_cal> <CR><LF>
$R047F,C2,<meter_1_cal>,<meter_2_cal><CR><LF>
$R047F,C3,<valve_1_cal>,<valve_2_cal>,<prod_1_cal>,
<prod_2_cal><CR><LF>
Bit Switch Byte 1 Switch Byte 2
0 boom 1 0
1 boom 2 0
2 boom 3 0
3 boom 4* prod 1 auto
4 boom 5* prod 1 manual
5 boom 6* prod 2 auto
6 0 prod 2 manual
71 1
* Booms 4, 5, and 6 are only in the SCS 710 Console strings.
NOTE:If prod auto and manual are both zero, the product is in Off.
For switch Byte Bits; 0 = off and 1 = on.
Data Strings:
$R047F,D1,<total_area>,<field_area><CR><LF>
$R047F,D2,<prod_1_volume>,<prod_ 2_volume><CR><LF>
$R047F,D3,<tank_1_volume>,<tank_2_volume>,<feet/meters><CR><LF>
Actual Rate:
$R047F,AR,<actual_rate_1>,<actual_rate_2><CR><LF>
Time/Date:
$R047F,TD,<hr:min>,<month/day/year>,<field_reference><CR><LF>
