CHAPTER 15
154 Viper/Viper 4+ Installation & Operation Manual
RECALIBRATE AB GUIDANCE PATH
The Recalibrate Guidance Path feature is intended to be used to reset an existing guidance path to the current
vehicle position to correct for issues such as GPS drift. This feature may also be useful to adjust an AB guidance
path for use with an implement with a different width than the implement used to record the path.
To clear the current AB guidance path:
1. Tap the AB Utilities widget to display the swath tools prompt.
2. Touch the More button to access the Nudge and Swath prompt.
NOTE: The nudge features are also available on the Nudge and Swath prompt. Refer to the Nudge Features
and Tools section on page 155 for assistance with using AB guidance nudge during field operations.
3. Select the Recal button. The AB path will reset to the center of the configured vehicle swath.
RESET AB GUIDANCE PATH
Multiple AB paths may be used during a field operation as desired for field guidance. Before a new AB guidance
path may be created during a field operation, the existing AB path must be cleared.
To clear the current AB guidance path:
1. Tap the AB Utilities widget.
2. Touch the Reset button.
SAVING GUIDANCE PATHS
Saving an AB guidance path allows the line to be assigned to a job profile or selected when setting up for a field
operation.
NOTE: Only the active AB guidance paths will be saved. Last pass paths will not be stored by ROS.
CAUTION
Please use caution when recalibrating a guidance
path loaded from previous field operations.
Contour paths may not provide anticipated
results and cause the equipment to swing or
cover areas unintended for coverage or into
nearby obstacles.
AB Utilities
More
Recalibrate
To Next Page
