SEE FIG. 11, 11A & 12
It is recommended that each side of the burner is serviced
individually so as not to get the components from the two
burners mixed up.
The correct combination of burner blast tubes are shown.
To remove blast tube, slacken two countersunk screws,
pull forward.
COOKER AND BOILER = Countersunk screws in tube
Fig. 12 DESN 515964
COOKER
BURNER
BOILER
BURNER
11
INTRODUCTION
Burner Servicing
4 VANES
Fig. 11 DESN 515963
Fig. 11A DESN 515977
10 VANES
