3.
1Controls—Axiomvariants
1 Touchscreen
2
Powerbutton
3
MicroSDcardreader(7”
displayonly)
4
MicroSDcardreader(9”&12”displays)
P oweringonthedisplay
WhenpowerisavailabletotheMFDbuttheMFDisswitchedoff,thePowersymbolwillbeilluminated.
Topoweronthedisplay:
1.S wipeyourfingerfromlefttorightacrossthe Powerbuttonswipearea.
TheMFDwillpowerup.
