Operation
5
Chapter Button
Hold
down for
on/off
Set-up
Button
Prompt
Alarm
Indicator
(Flashes)
Battery
Level
Set Button
Page and Adjust Buttons
Hold down
for
Backlighting
Descriptive
Text
Charge
Rate
2 Operation
Important:
Ensure that the "Auto Network" procedure described on the yellow
instruction sheet and full Setup and Calibration has been performed
correctly before attempting to use your Micronet system.
2.1 Display Information
Display Icons
The following icons are used to display information on the screen:
KKTTSS
,
KKPPHH
,
MMPPHH
to display speed units
KKTTSS
,
MM
to display wind speed units
TTRRUUEE
,
AAPPPP
to indicate True or Apparent wind
TTRRUUEE
,
MMAAGG
to indicate True or Magnetic bearings and headings
LLAATT
,
LLOONN
to indicate Latitiude or Longitude
LLOOGG
,
TTRRIIPP
to indicate a Total Logged or Trip distance
oo
to indicate degrees of angle or temperature
