Power On
Is the water
temperature displayed?
NO
YES
Push MODE
button to select
"Pool" or "Spa"
Push UP or DOWN
button to scroll to
desired temperature
NO
Water temperature
and set
temperature
displayed?
YES
“Heating” will
display briefly
NO
NO
YES
YES
Water temp displayed?
(rectified)
Heater Fired?
END
• Check On/Off switch (under lid on control panel)
• Check for 120/240 volts to the transformer
(time clock, circuit breaker, wire connections)
• Check for 24 volts to Circuit Board (P6 connector)
“Remote” and Water Temperature displayed
(a remote control is controlling the heater)
Note: Disconnect the remote by turning the
remote function off. See page 38 for instructions.
NO
YES
Is a fault code displayed and flashing?
Diagnostic Readouts
“Sensor Failure,” “Sensor Open” or “Sensor Short” -
Temperature sensor out of range (replace sensor)
Verify power at MV on P-4 Terminal on digital circuit board.
Verify power to valve MV voltage. (Replace valve.)
“Spark”
Sensor Failure
Inspect thermister, wires, and connector at Terminal P1
Check resistance value of the thermister. Reference to chart below.
Replace thermister if not within 10% of values shown below.
If okay, replace Circuit Board.
Temp Degrees F 40 50 60 70 80 90 100 106
Resistance (k)
261.1 199.0 153.1 118.8 93.0 73.3 58.3 51.0
If okay, replace Circuit Board
Sensor resistance at various temperatures
“Water Sw Open” Water flow switch. Verify water flow and pressure. If water
connections were reversed, verify the location and direction
of the water flow across the flow switch.
CLEAN FILTER / STRAINER - backwash if neccessary.
“Hi Limit 1 Fault” High limit switch. Verify water flow. Inspect internal
“Hi Limit 2 Fault” bypass valve.
“Clock/Fireman Sw” Fireman or Remote switch connected to safety loop is in the
OFF mode.
“Vent/Field Sw #1” Vent switch open. Check connections to the board.
Check for blockages in the vent.
“Ignition Lockout” Ignition lockout. Check spark (bad ignition circuit or
hi-tension wire).
“Ignition Failure” Ignition failure. Verify gas to the heater. Verify valve operation
(gas present at tube fitting).
To Next Page
