TV1I0-POSITION FLAPS
(TC-I
THRU
TC-2002)
NOTE
Beech
recommends
the
use
of
the
flap
travel
gage
shown
in the
GENERAL
INFORMATION
section
of
this
manual.
Position
the
travel
gage
on
the
flap
just
aft of
the
flap
actuator.
Two
limit
switches control
the
uplimit
position
andthe
downlimit
position.
To
adjust
the
flap
to
neutral
(UP
position).
loosen the
screws
on
the
switch
assembly
so
that
it
can
pivot
on
the
forward
elongated
hole.
Adjust
the
switch
to
stop
the
flaps
in
neutral.
NOTE
Rig
the
flaps
under
a
simulated
flight
load to
minimize
overtravel
(coasting)
of
the
motor
after the
limit
switch has
been
actuated.
Move
the
flap
control
switch
to
the
down
position
and
measure
the
flap
travel with
a
flap
travel
gage.
Adjust
the
downlimit
switch
to obtain
28"
to
30"
of
down
travel.
THREE-POSITION
FLAPS
(TC-2003
AND
AFTER;
TE-
I
AND
A~TER;
TH-
I
AND
AFTER)
NOTE
Beech
recommends
the
use
of the
flap
travel
gage
shown
in
the
GENERAL
INFORMATION
section
of
this
manual.
Place
the travel
gage
on
the
flap just
aft
of
the
flap
actuator.
Four
limit
switches
tone
for
up
position,
two for
approach
position
and
one
for down
position)
control
the
travel
of
the
flaps.
Use
a
flap
travel
gage
to
measure
flap
travel
when
adjusting
the
limit
switches.
NOTE
Rig
the
flaps
under
a
simulated
flight
load
to
minimize
overtravel
(coasting)
of
the
flap
motor
after
the limit switch
has
been
actuated.
a.
Adjust
the
uplimit
switch
so
that
the
flap
stops
at
neutral
(UP position).
b.
Adjust
the
14"
(outboard)
limit switch
in its
mounting
slot
to
stop
the
flap
at
14"
to
14.5"
after the
flap
moves
from
the
UP
position
to
the
APPROACH
position.
c.
Adjust
the
16"
(inboard)
limit
switch in its
mounting
slot
to
stop
the
flap
at
15.5"
to
16"
after
the
flap
moves
from
the DOWN
position
to
the
APPROACH
position.
d.
Adjust
the
downlimit
switch in
its
mounting
slot
to
stop
the
flap
at
28" to
30"
of
down
travel.
e.
Remove
the
bolt
attaching
the
right
actuator
to
the
right
flap.
f. Turn
the
jackscrew
on
the
right
actuator
in
or
out
until
the
right flap
aligns
with
the
left
flap.
g.
Install
the
bolt
connecting
the
right
actuator
to
the
flap.
