SAVE DATA PROGRAM
Program select.
The parameter value setting up in this screen does not affect charge or
discharge process. They only represent the specification of the battery.
The following screens will automatically be displayed exactly matched
battery type you set up. The example shows the battery pack of NiMH,
12cells and 3000mAh of capacity.
Set up the charge current for manual charge mode, or the current limit
for automatic charge mode. Each mode can be switched by pressing
INC and DEC button at the same time when the current field is blinking.
Setting up discharge current and final voltage.
Setting up the sequence of charge and discharge, and the cycling
number.
Saving the data.
It has the data storage and load program for your convenience. This feature can store up to 5 battery data
by number that represent the individual specification of the batteries you are using. They can be called back
for the process of charging or discharging without setting up the program again. To set up the parameter
value in the program, press START/ENTER key to make it blink then change the value with INC or DEC key.
-
16
-
Set up the charge current for manual charge mode, or
the current limit for automatic charge mode. Each mode
can be switched by pressing INC and DEC button at
the same time when the current field is blinking.
Setting up discharge current and final voltage.
Setting up the sequence of charge and discharge, and
the cycling number.
Saving the data.
Program select.
The parameter valaue setting up in this screen
does not affect charge or discharge process. They
only represent the specification of the battery. The
following screens will automatically be displayed
exactly matched battery type you set up. The
example shows the battery pack of NiMH, 12cells and
3000mAh of capacity.
