CHARGER LAYOUT
Input Power Cable
AC100-240V
Charging lead
connector
4mm banana female
BATT TYPE/STOP
To select main program
To stop operation
DEC/INC
To select sub program
To alter the value
START/ENTER
To resume or start the
operation
Individual cell
connector port
Input Power Cable
DC11-18V
3-pin port for tem-
perature sensor
