13
LITHIUM BATTERY (LILO/LIPO/LIFE) PROGRAM
CHARGING LITHIUM BATTERY
This program sets the maximum charge capacity that will be supplied
to the battery during charge. If the delta-pack voltage is not detected
nor the safety timer expired by any reason, this feature will automati
-
cally stop the process at the selected capacity value.
The beep sounds at every time pressing the buttons to confirm your
action. The beep or melody sounded at various times during operation
to alert different mode changes. These audible sounds can be on or off.
This program monitors the voltage of input battery. If the voltage drops
below the value you set the operation forcibly terminated to protect
the input battery.
-
9
-
L
6. Lithium battery(Lilo/LiPo/LiFe)program
These programs are only suitable for charging and discharging Lithium batteries
with a nominal voltage of 3.3V, 3.6V and 3.7V per cell. These batteries need to
adopt different charge technique is termed a constant voltage(CV) and constant
current(CC) method. The charge current varies according to the battery capacity and
performance. The final voltage of charge process is also very important; it should be
precisely matched with the charade voltage of the battery. They are 4.2V for LiPo, 4.1V
for Lilo, and 3.6 V for LiFe. The charge current and nominal voltage as for cell count
set on the charge program must always be correct for the battery to be charged.
When you are willing to alter the parameter value in the program, press Start/
Enter key to make it blink then change the value with INC or DEC key. The value will
be stored by pressing Start/Enter key once.
6.1 Charging Lithium Battery
The left side of the first line shows the type of battery
you select at the users setting. The value on the left
side of second line sets a charge current and the value
on the right side of second line sets the voltage of the
battery pack.
After setting the current and voltage press Start/Enter
key for more than 3 seconds to start the process.
(Charge current:0.1~7.0A,Voltage:1~6 series)
-
9
-
L
6. Lithium battery(Lilo/LiPo/LiFe)program
These programs are only suitable for charging and discharging Lithium batteries
with a nominal voltage of 3.3V, 3.6V and 3.7V per cell. These batteries need to
adopt different charge technique is termed a constant voltage(CV) and constant
current(CC) method. The charge current varies according to the battery capacity and
performance. The final voltage of charge process is also very important; it should be
precisely matched with the charade voltage of the battery. They are 4.2V for LiPo, 4.1V
for Lilo, and 3.6 V for LiFe. The charge current and nominal voltage as for cell count
set on the charge program must always be correct for the battery to be charged.
When you are willing to alter the parameter value in the program, press Start/
Enter key to make it blink then change the value with INC or DEC key. The value will
be stored by pressing Start/Enter key once.
6.1 Charging Lithium Battery
The left side of the first line shows the type of battery
you select at the users setting. The value on the left
side of second line sets a charge current and the value
on the right side of second line sets the voltage of the
battery pack.
After setting the current and voltage press Start/Enter
key for more than 3 seconds to start the process.
(Charge current:0.1~7.0A,Voltage:1~6 series)
These programs are only suitable for charging and discharging Lithium batteries with a nominal voltage of
3.3V, 3.6V and 3.7V per cell. These batteries need to adopt different charge technique is termed a constant
voltage(CV) and constant current(CC) method. The charge current varies according to the battery capacity
and performance. The final voltage of charge process is also very important; it should be precisely matched
with the charade voltage of the battery. They are 4.2V for LiPo, 4.1V for Lilo, and 3.6 V for LiFe. The charge
current and nominal voltage as for cell count set on the charge program must always be correct for the
battery to be charged.
When you are willing to alter the parameter value in the program, press Start/Enter key to make it blink then
change the value with INC or DEC key. The value will be stored by pressing Start/Enter key once.
The left side of the first line shows the type of battery you select at the users
setting. The value on the left side of second line sets a charge current and the
value on the right side of second line sets the voltage of the battery pack.
After setting the current and voltage press Start/Enter key for more than 3
seconds to start the process.
(Charge current:0.1~7.0A,Voltage:1~6 series)
