LOAD DATA PROGRAM
This program calls back the data that was stored at ‘Save Data’ program. To load the data, press Start/Enter
key once to blink the data number field and select the number using INC or DEC key then press Start /Enter
key for more than 3 seconds.
You can inquire various information on LCD screen during charging or discharging process. When you press
DEC button the charger shows the establishment of user settings. And also you can monitor the voltage of
individual cell by pressing INC button when the individual connection cable is linked to the Lithium battery
being processed.
Program select
Select the data number you wish to load.
The data matched with the number will be displayed at this time.
Loading the data.
Set-voltage protection
Set the charge-discharge capacity of the protection.
Set the charge and discharge time protection.
-
17
-
11. Load Data Program
This program calls back the data that was stored at 'Save Data' program.To load
the data, press Start/Enter key once to blink the data number field and select the
number using INC or DEC key then press Start /Enter key for more than 3 seconds.
Program select.
Select the data number to be called back.
The data matched with the number will be displayed at
this time.
Loading the data.
12. Various information during the process
You can inquire various information on LCD screen during charging or discharging
process. When you press DEC button the charger shows the establishment of user
settings. And also you can monitor the voltage of individual cell by pressing INC
button when the individual connection cable is linked to the Lithium battery being
processed.
Set-voltage protection.
Set the charge-discharge capacity of the protection.
Set the charge and discharge time protection.
-
17
-
11. Load Data Program
This program calls back the data that was stored at 'Save Data' program.To load
the data, press Start/Enter key once to blink the data number field and select the
number using INC or DEC key then press Start /Enter key for more than 3 seconds.
Program select.
Select the data number to be called back.
The data matched with the number will be displayed at
this time.
Loading the data.
12. Various information during the process
You can inquire various information on LCD screen during charging or discharging
process. When you press DEC button the charger shows the establishment of user
settings. And also you can monitor the voltage of individual cell by pressing INC
button when the individual connection cable is linked to the Lithium battery being
processed.
Set-voltage protection.
Set the charge-discharge capacity of the protection.
Set the charge and discharge time protection.
INFORMATION DURING THE PROCESS
