iii i i
Front Speake_ se!ection Large/Sma!!
Center Speaker Selection Large/Sma!l/None
Surround Speaker Selection Large/Small/None
Subwoofer selection Yes/No
Subwoofer Phase + /_
Front Speaker distance O_40 ft
Centre Speaker distance 0-40 ft
Rear Speaker distance O-40 ft
Speaker Icons
The receiver shows you the speakers' types and set-
tings on the display with the following icons:
Bypressing the button repeatedly while display isstill
showing :5_ _:;, the display will toggle among: front,
center, surround, subwoofer, subwoofer phase and
speakers' distance setup. You can now set the volume
size or speakers' distance by rotating the MULTI
JOG.
Note:
• The sub-woofer selection will always be YESwhen
the main speakers are set to small (SML).
• For the subwoofer phasesetting, it will be affected
by how you locate the subwoofer. Tryboth + and -
settings and select the one that has better bass effect.
Speaker Distance
To make the surround sound more effective and suit
the acoustic conditions in your listening room, you
need to input the distance of the speakers measured
from your favourite listening position. The receiver
will adjust the appropriate delay compensation for
yOU.
L/R alL,_._ _1_- L/R
SU R/_._.___ _S UR
DisplayingProgramFormats
When a digital source is playing, the receiver will
automatically switch to the proper surround mode
and indicates on the speaker icons on the right-hand
side of the display. (Seediagram)
It isimportant to note, however,
that not all Dolby Digital sourcesare
encoded with the full complement
of five channels plus LFE*.Speaker
iconsshow how many and which
speaker you have enabled (See"Fine
Setting of the Speakers") and the
letters inside the speaker iconsshow which channel is
present in the source information. For example, the
diagram shown means you have all the five speakers
and subwoofer enabled and the digital sourcesyou
played have five channels plus LFEcomplemented.
* I_E stands for Low Fz_quency Effect, TNe Lndication "LFE"
if the digital scurce o_ntains LFE z_fc_1_mticn, In tPliscase, the bass
sz_ml _ili be deli-veI_d to th_ mlb_oofer, offez'_7_ _sre _}_'&c deep
bass sc_i effects, If tbe letter is flashy, tbe sz_ml _s either tco
weak or just zone,
Note: The receiver hasdefaulted the following dis-
tances:
Main speakers (L/R) 15 ft
Center speaker (Cch)*15ft
Rearspeaker (SUR) 10 ft
(* Center speaker isavailable only when Dolby Digital
isactive)
•-................................................................................................................................................................................ .-°"
13
