Each program shows two editable parameters and an effect return level control. The
editable parameters for REV programs are:
DEC (sec) – Decay in seconds
DAMP – Frequency Damping
01 – 40 – REVERBS
For DLY programs:
TIM (ms) – time in milliseconds
FDBK – Feedback
41 – 60 – DELAYS
For MOD programs:
RATE – rate (in Hz)
DEPTH – depth
61 – 80 – MODULATIONS
19
PAIR button.
Pressing the PAIR button initiates the Bluetooth discovery sequence, required when a new
pairing operation has to be performed on a smartphone, tablet or notebook. The green
LED will blink as long as a Bluetooth device is associated. When the device is connected,
the green LED will be steadily lit. Now it is possible to control the EVOX JMIX8 system via
the Android or iOS app. Furthermore, a Bluetooth audio streaming is enabled to stereo
channel 7/8 (see section 10 of this chapter)
20
USB.
The “type B” USB connector is used for future firmware upgrades.
