RCF EVOX JMIX8 User Manual

6
ENGLISH
Remove the rubber band and take out the
satellite
Screw the lower part of the satellite speaker
stand (the pole) into the subwoofer insert for
pole mounting.
Screw the telescopic upper part of the satellite
speaker stand into its lower part.
Loose the stand bolt, adjust the satellite
speaker height from the floor and tighten the
bolt again, then insert the satellite speaker
into its complete stand and aim it correctly.
INSTALLATION

RCF EVOX JMIX8 Specifications

General

Max SPL	128 dB
Amplifier Power	1400 W Peak, 700 W RMS
Amplifier Type	Class D
Bluetooth	Yes
DSP	Yes
Weight	24.4 kg / 53.79 lbs
Horizontal Coverage Angle	120°
Vertical Coverage Angle	30°
Frequency Response	40 Hz - 20 kHz
Tweeter	8 x 2"
Mixer	8-channel Digital Mixer
Connectors	XLR
