RCF QPS 9600 - SpeakON Connector Wiring; Wiring Configurations; Cooling Requirements; Airflow and Ventilation

14
ENGLISH
SPEAKON CONNECTOR WIRING
COOLING REQUIREMENTS
SINGLE CHANNEL DUAL CHANNEL
(
7A
AND
7C
ONLY)
BRIDGE
(
7A
AND
7C
ONLY)
QPS 9600 has a forced air cooling system to maintain a low operating temperature.
Make sure there is enough space in the front (and all around) of all ampliers.
If ampliers are rack-mounted, do not use doors or covers on the front and the rear of rack
cabinets.
1+
2+
1–
2–
_
+
1+
2+
1–
2–
_
+
1+
2+
1–
2–
+
_
+
_
B/D
A/C
