RCF QPS 9600 User Manual

15
ENGLISH
SPECIFICATIONS
RATED OUTPUT POWER (single channels)
4 x 1300 W @ 8 Ω
4 x 2200 W @ 4 Ω
4 x 2400 W @ 2 Ω
RATED OUTPUT POWER (bridged outputs)
2 x 4400 W @ 8 Ω
2 x 4800 W @ 4 Ω
Frequency response 20 Hz ÷ 25 kHz (± 0.5 dB)
Total harmonic distortion 0.1% (rated power, 4 Ω)
Signal / noise ratio 110 dB
Amplier gain (selectable) 23 ÷ 44 dB (3 dB steps)
Input impedance 20 kΩ (balanced), 10 kΩ (unbalanced)
Protections DC, HF, current, thermal drift
Operating voltage 115 / 230 V (according to the model), 50/60 Hz
Max. power consumption 1950 W
Dimensions (w, h, d) 483 mm, 88 mm, 445 mm (2U – 19” rack)
Net weight 16 kg
Gross weight 19.5 kg

RCF QPS 9600 Specifications

General

Built-in display	Yes
Purpose	Performance/stage
Cooling type	Passive
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
Amplifier class	A/B
Frequency range	20 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	300 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.01 %
RMS power output per channel (4 Ohm)	185 W
RMS power output per channel (8 Ohm)	125 W
Bridge-mode power output per channel (8 Ohm)	375 W
Line inputs (RCA)	2
Speakers connectivity type	Binding post
LED indicators	Power, Status

Weight and Dimensions

Depth	101.6 mm
Width	257.5 mm
Height	482.6 mm
Weight	8800 g
