EPSILON ES2,ES4
43
+4 1 00h…FFh CRC8
A2.3.2.2.3 Reading of probe’s length parameter (command 4Dh).
Command is designed for reading of current value of probe’s length parameter.
Command format:
Drift, byte
Size of field, byte
Value Description
0 1 31h Prefix
+1 1 00h…FFh
Network address of
acceptor
+2 1 4Dh Command code
+3 1 00h…FFh CRC8
Answer format:
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 4Dh Command code
+3 1 00h…07h
Parameter of probe’s
length
+4 1 00h…FFh CRC8
Probe’s length parameter decoding
Value of probe’s
length parameter
Manufacturer's type
mark
Allowable length of
probe, mm
Notes
0 User’s L 0…260
Calibration is made
during installation
1 User’s H 710…800
Calibration is made
during installation
2 260 150…340
Manufacturer’s
calibration
3 350 270…430
Manufacturer’s
calibration
4 440 360…520
Manufacturer’s
calibration
5 530 450…610
Manufacturer’s
calibration
6 620 540…650
Manufacturer’s
calibration
7 710 630…710
Manufacturer’s
calibration
A2.3.2.2.4 Select of probe’s length parameter (command 4Eh).
The command is designed for selecting of probe’s length in a line from 0 to 7.
