RCS EPSILON ES2 User Manual

EPSILON ES2,ES4
47
Appendix 4
CONNECTION OF SENSORS ES2 AND ES4 TO CONCENTRATOR
OF FUEL LEVEL SENSORS “DALCON”
Concentrator of fuel level sensors "LLS DALCON" is designed for evaluating of current volume
of liquid in one or two tanks and for organization of interface of interaction with external devices
of data collection (recorders).
The concentrator also has the ability to control external status displays (needle indicator of fuel
level and light indicator "reserve").
A4.1 Connection
For connection of sensors to the concentrator you need to use the "Manual for installation of
concentrator of fuel level sensors LLS DALCON" (Ed. 1.3, Omnicomm 2008,
http://rega78.ucoz.ru/_ld/0/9_Installation_DA.pdf or later) and this appendix.
You can connect two sensors with the same interfaces RS485 (pic.A4.1) or different interfaces
RS485 or RS232 (Pic. A4.2) to connector MF-20F on the concentrator’s body.
To connect three or more sensors to concentrators DALCON cascading connection is used.
(see afore-mentioned manual).
