RCS EPSILON ES2 User Manual

52
Appendix 5
CONNECTION OF SENSORS ES4 TO ONBOARD MONITORING
CONTROLLERS OF TRANSPORT SERIES «AвтоГРАФ-GSM»
The on-board transport monitoring controller "AвтоГРАФ-GSM” is an electronic recorder that
registers vehicle movements by recording the route in the form of points with coordinates
received from satellite system GPS (NAVSTAR) or GLONASS.
Additionally, it makes records of some other device parameters: speed, fuel level and condition
of different vehicle sensors.
To connect to FLS RS485 port is used.
For connecting of 1 on more fuel level sensors to the range of devices ""AвтоГРАФ-GSM” you
have to use manufacturer’s manual " WORK_RS485 User manual.pdf", and also the following
scheme:
ES4
RS485
черный
зеленый
желтый
красный
ES4
RS485
черный
зеленый
желтый
красный
ES4
RS485
черный
зеленый
желтый
красный
...
+U
16 17 18 11 12 5
6
7 8
F C
13 14 15 9 10 1 2 3 4
E B
A
B
-U
You can also use additional installation manuals on the site of the manufacturer:
http://snavi.ru/instrykciya-po-ystanovke/index.html.
red
red
red
Green
Yellow
Black
Green
Yellow
Black
Green
Yellow
Black
