TIMER MODE (cont.)
3.4 Disconnection
3.4.1 No Remaining Credit
When the prepaid credit expires the timer main contactor will be open, thus
disconnecting the power. To restore power and restart the timed cycle, token
cards must be inserted.
3.4.2 Reverse Energy Detection
If reverse power is detected above a pre-determined level the display will
indicate “RED” (Reverse Energy Detection). Reverse detection can only be
reset via the command card.
3.5 Prepayment Card Tokens
3.5.1 Valid Cards
When a valid token card is inserted, time is credited to the timer and its
acceptance is indicated by the message “XXXX Token” being displayed
momentarily. On removal the card is erased and visibly marked. The maximum
credit is limited to 1440 minutes at which point the display will change to
Maximum Reached. Three examples are given below:
Example 1:
Example 2:
Example 3:
3.5.2 Card Errors
The message “CARD ERROR” may be displayed if the token card was
inserted too quickly, too slowly or the token card was invalid, the message
“Maximum Reached” is displayed if a token card is inserted that would cause
the pre-paid credit to become greater than Maximum Time hh:mm set. If either
of the above messages are displayed then on removal, the card is not erased
and may be used at a later date.
DISPLAY ACTION
DISPLAY ACTION
DISPLAY ACTION
Timer Countdown 00:00:00 Insert value One Token Card
One Token 1 x Set time credited to timer
Timer Countdown 00:00:00 Insert value Five Token Card
Five Token 5 x Set time credited to timer
Timer Countdown 00:00:00 Insert value Ten Token Card
Ten Token 10 x Set time credited to timer
12
