•This pull-down list contains all the display options the Bee8 can accomodate. The Choices are 1920X1080, 1440X1050,
1440X900, 1366X768, 1280X1024, 1280X800, 1024X769, 1280X720
1. Output Resolution (3 live inputs)
•The source input panel allows you to select which inputs are active on the Bee8 when the panel is in Manual mode.
The Picture above shows the panel in manual mode, with all 3 inputs selected, and all sources being High Definition.
When in three source mode, the layout choices are montage, or three in line.
2. Source Input Panel
•Video Layout defines the arrangement of the sources as displayed, recorded, an streamed. As mentioned above, when
3 sources are selected, the layout choices are montage or three in line. Please see the picture below to for a similar
explanation for two input mode. These layout arrangements are changeable while recoding and streaming. After each
change, press save to commit the action. A dialog box will confirm the setting change.
3. Video Layout
