Check 65mm flue piece for correct shape and
fitment onto appliance spigot.
Ensure ends are burr free and round, test fit flue
will slide over connection.
Recommended Silicon – Non-acetic, neutral cure 150degc or higher temperature rated.
Bostik RTV 926 or similar.
Apply an 8mm thick silicon bead fully around heater connection approx. 10mm from the top.
Apply an 8mm thick silicon bead fully around the lower fan connection spigot approx. 10mm from
the end.
Apply an 8mm silicon bead fully around
the inside of the flue end, both ends.
Turn fan assembly upside down and slide
65mm flue section fully onto spigot.
Fit flue clamp and tighten clamp fully.
Wipe excess silicon, visually check
connection to ensure connection is fully
sealed.
INSTALLATION INSTRUCTIONS (continued)
17
