CONVERSION INSTRUCTIONS (continued)
66
6/ Check all wires are sitting correctly, flush to
front wall. Ensure spark lead is not broken or
excessively bent. Ensure lead hole is still
sealed. (High temperature silicon is suitable for
resealing.)
BURNER REFITMENT
1/ Carefully place burner into firebox, supporting
LH end of the burner.
2/ Tighten gas pipe connection to the end of the
burner. Burner can now be lowered fully into the
firebox.
3/ Refit burner retaining screws (2 off)
4/ Refit End cover plates and refit holding screws.
(Screws only need to be done finger tight)
5/ Replace media as per media fitment
instructions.
6/ Refit door. Check door seal is sitting correctly.
Hang door onto firebox. Fit screw and lift door
slightly to locate.
10 x screws to be refitted
DO NOT OVERTIGHTEN SCREWS – Hand
tight is suffient for door to seal.
