13
Prepare RTD Wires For Grill Installation
Pull all the slack from 5 pin connector and RTD wire
connector through rubber grommeted hole on left
side of grill body. Be sure not to damage wiring when
installing grill body (#1) onto cart in next step.
DO NOT ATTEMPT
TO COMPLETE
STEP 10 WITHOUT
ASSISTANCE!
Lift Grill Body Onto Cart
Lift grill body (#1) by pull bar handles and
place onto locked cart WITH ASSISTANCE.
ENSURE ALL CASTER
WHEELS ARE LOCKED!
LOCKED &
CORRECT!
UNLOCKED &
INCORRECT!
