SETTING THE CONTROL OPTION
With reference to the Menu Structure, carry out the following steps.
1. Press “Menu” is displayed.
2. Press (to move to next parameter),
“TIME” is displayed.
3. Press (to move to next parameter),
“OPtn” is displayed.
4. Press option currently set “OP-X” is displayed,
alternatively with “AdJ-“, indicating you
are in data change or adjust mode).
5. Use the button to increment the Option UP, or
the temperature button to decrement
the Option DOWN). Note that the “AdJ-“
prompt is not displayed whilst the up/
down buttons are pressed.
6. If setting the Option 1 to 4, then press to return
to the main menu loop
then press the to exit menu
mode and return to normal mode.
7. If the Option is set to option 5, then this is the User Selectable
time switch settings.
Press “Menu” to enter User Time-ON-1,
“onu1” is displayed.
8. This is the time of day you want the heat pump temperature
mode enabled.
9. Press to display the current time-On setting.
The “AdJ-“ prompt will again appear.
10. Use the to increment the Time-ON UP, or the
temperature button to decrement the
Time-ON DOWN). The longer the button
is pressed the faster the time will
change. Note that the “AdJ-“ prompt
is not displayed whilst the up/down
buttons are pressed.
11. Once the correct time-ON is displayed,
press the Menu button to Accept.
12. Press button to move to the User Hours-
Run-1, “hru1” is displayed.
13. Press button to display the current Hours
Run setting. The “AdJ-“ prompt will
again appear.
14. Use the Use the Boost Button to increment
the Hours Run UP, or the temperature
button to decrement the Hours Run
DOWN). The longer the button is
pressed the faster the time will change.
Note that the “AdJ-“ prompt is not
displayed whilst the up/down buttons
are pressed.
15. Press Once the correct Hours Run is
displayed, press the Menu button to
accept.
16. Press A second user selectable time switch
setting is also available. Press the
Temperature button to move to the
User Time-ON-2, “onu2” is displayed.
Repeat steps 9 to
11. Press to adjust, but if not required move to
the next step.
17. Press button to move to the User Hours-
Run-2, “hru2” is displayed.
18. Press button to display the current Hours Run
setting. The “AdJ-“ prompt will again
appear.
19. Use the button to increment the Hours Run UP,
or the temperature button to decrement
the Hours Run DOWN). The longer the
button is pressed the faster the time will
change. Note that the “AdJ-“ prompt
is not displayed whilst the up/down
buttons are pressed. If the second user
selectable time switch is not required,
it can be disabled by setting the user
hours run-2 period to 00 hrs.
20. Press Once the correct Hours Run is
displayed, press the Menu button to
accept.
21. Press Once fi nished, simply press the Boost
button (exit) to revert to the normal
display or wait 30 seconds for auto
6
