Record Power DML250 - Getting to Know Your Lathe

8 8
1 Motor
2 Motor securing lever
3 Motor positioning lever
4 Motor pulley access hatch
5 Headstock
6 Hand wheel
7 Spindle pulley access hatch
8 Spindle
9 Faceplate
10 4 prong drive centre
11 Tool rest
12 Tool rest holder
13 Tool rest holder locking lever
14 Tool rest locking lever
15 Revolving centre
16 Tailstock barrel
17 Tailstock
18 Tailstock barrel locking lever
19 Tailstock hand wheel
20 Tailstock locking lever
21 On / off switch
22 Lathe bed
7. Getting to Know Your Lathe
12
4
21
5
11 14
13 22
15 1716 18 19
20
8 9
76
123
10
