red lion P16 User Manual

14
06676
-)&8
DISPLAY VALUE SCALING POINT 2
.555 to 5555
Enter the second coordinate Display Value by using the arrow
keys.
86766
1(&8
INPUT VALUE SCALING POINT 2
6766 to 86766 mA
6766 to 06766 V
For Key-in Method, enter the second coordinate Input Value
by using the arrow keys. To allow the P16 to “learn” the signal,
use the Applied Method. For Applied Method, press !. The °
annunciator is turned on to indicate the applied method. Adjust
the applied signal level externally until the appropriate value
appears under
1(&8. Using either method, press " to store the
value for
1(&8. (The controller can be toggled back to the Key-in
Method by pressing ! before ".)
676
)&#"
SETPOINT LOW LIMIT
.555 to 5555
The controller has a programmable low setpoint limit value to
restrict the setting range of the setpoint. Set the limit so that the
setpoint value cannot be set below the safe operating area of the
process.
55575
)&*1
SETPOINT HIGH LIMIT
.555 to 5555
The controller has a programmable high setpoint limit value to
restrict the setting range of the setpoint. Set the limit so that the
setpoint value cannot be set above the safe operating area of the
process.
&#"4
12&,
USER INPUT FUNCTION (OPTIONAL)
The controller performs the selected User Input function (User
Input available only on models with alarms), when the User
terminal 1 is connected (pulled low) to Common terminal 8.
No Function: No function is performed.
Program Lock: The Configuration Loop is locked, as long as
activated (maintained action).
Integral Action Lock: The integral action of the PID
computation is disabled (frozen), as long as activated
(maintained action).
Auto/Manual Select: This function selects (maintained action)
Automatic (open) or Manual Control (activated).
Setpoint 1 or 2 Select: This function selects (maintained action)
Setpoint 1(open) or Setpoint 2 (activated) as the active
setpoint.
Setpoint Ramp Disable: The setpoint ramping feature is
disabled, as long as activated (maintained action). Any time
the user input is activated with a ramp in process, ramping is
aborted.
Reset Alarms: Active alarms are reset, as long as activated
(maintained action). Active alarms are reset until the alarm
condition is cleared and triggered again (momentary action).
SELECTION FUNCTION SELECTION FUNCTION
NONE
No Function
SPt
Setpoint 1 or 2 Select
PLOC
Program Lock
SPrP
Setpoint Ramp Disable
ILOC
Integral Action Lock
ALrS
Reset Both Alarms
trnF
Auto/Manual Select
("('
/012
F1 KEY FUNCTION
The controller performs the selected F1 key function, when !
is pressed while in the Display Loop. In any other loop or module
location, pressing ! will perform an escape to the Display Loop.
No Function: No function is performed.
Auto/Manual Select: This function toggles (momentary action)
the controller between Automatic and Manual Control.
Setpoint 1 or 2 Selection: This function toggles (momentary
action) the controller between Setpoint 1 and Setpoint 2.
Reset Alarms: This function can be used to reset one or both of
the alarms when activated (momentary action). The alarm will
remain reset until the alarm condition is cleared and triggered
again.
Reset Both Alarms
ALrS
Setpoint 1 or 2 Select
SPt
Reset Alarm 2
A2rS
Auto/Manual Select
trnF
Reset Alarm 1
A1rS
No Function
NONE
FUNCTIONSELECTIONFUNCTIONSELECTION
