red lion P16 User Manual

4
18-36 VDC/24 VAC 85 to 250 VAC
Relay — T1610010 T1610000
Relay Yes T1611110 T1611100
T16 Logic/SSR — T1620010 T1620000
Logic/SSR Yes T1621110 T1621100
Analog Out * Yes T1641110 T1641100
Relay — P1610010 P1610000
Relay Yes P1611110 P1611100
P16
Logic/SSR — P1620010 P1620000
Logic/SSR Yes P1621110 P1621100
Analog Out * Yes P1641110 P1641100
MODEL NO. MAIN CONTROL 2 ALARMS & USER INPUT
PART NUMBERS
* Analog out may be used for retransmitted signals. When using analog output for retransmitted signals,
AL1 becomes main control O1, if selected for heating in the analog out models.
MODEL NO. DESCRIPTION PART NUMBERS
TP16
Programming Kit 1 : Includes Software, Comms Module w/
9-pin connector and cable, and 115 VAC Power Adapter
TP16KIT1
Programming Kit 2 : Includes Software, Comms Module w/
9-pin connector and cable
TP16KIT2
RLY
External SSR Power Unit (for Logic/SSR models) RLY50000
Single Phase Din Rail Mount Soild State Relay RLY60000
Three Phase Din Rail Mount Soild State Relay RLY70000
ACCESSORIES
Ordering Information
Ordering Information
BLOCK DIAGRAM
*AL1 becomes main control O1, if selected for heating
in the analog out models.
