SAFETY SUMMARY
All safety related regulations, local codes and instructions that
appear in the manual or on equipment must be observed to
ensure personal safety and to prevent damage to either the
instrument or equipment connected to it. If equipment is used in
a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Do not use the controller to directly command motors, valves,
or other actuators not equipped with safeguards. To do so can be
potentially harmful to persons or equipment in the event of a fault
to the controller. An independent and redundant temperature limit
indicator with alarm outputs is strongly recommended.
Product F
Product F
eatures Continued
eatures Continued
CAUTION: Read complete
instructions prior to installation
and operation of the unit.
CAUTION: Risk of electric shock.
General Specifications
General Specifications
1. DISPLAY: 2 Line by 4-digit, LCD negative image transmissive
with backlighting.
Top (Process) Display: 0.3
" (7.6 mm) high digits with red
backlighting.
Bottom (Parameter) Display: 0.2
" (5.1 mm) high digits with
green backlighting.
2. ANNUNCIATORS:
Status Annunciators:
O1 - Main control output is active.
O2 - Cooling output is active (when Alarm 2 is used for cooling).
A1 - Alarm 1 output is active.
A2 - Alarm 2 output is active.
°F, °C - Temperature units.
%PW - Output power percentage is shown in Bottom display.
MAN - Controller is in Manual Mode.
R - Ramping Setpoint indicator.
% - Percent indicator (P16 models only).
Display Messages:
!"#"#$ - Measurement exceeds + sensor range
!%#%#$ - Measurement exceeds - sensor range
!"&'($ - Open sensor is detected (T16 only)
!)*+,$ - Shorted sensor is detected (RTD only)
!)'()$ - Measurement exceeds controller limits (P16 only)
!----$ - Display value exceeds + display range
!.---$ - Display value exceeds - display range
3. POWER:
Line Voltage Models:
85 to 250 VAC, 50/60 Hz, 8 VA
Low Voltage Models:
DC Power: 18 to 36 VDC, 4 W
AC Power: 24 VAC, ±10%, 50/60 Hz, 7 VA
4. CONTROLS: Three rubber push buttons for modification and
setup of controller parameters. One additional button (F1) for
user programmable function. One external user input (models
with alarms) for parameter lockout or other user
programmable functions.
5. MEMORY: Nonvolatile E
2
PROM retains all programmable
parameters.
6. ISOLATION LEVEL:
AC power with respect to all other I/O: 250 V working (2300
V for 1 minute)
Sensor input to analog output: 50 V working (500 V for 1
minute)
Relay contacts to all other I/O: 300 V working (2300 V for 1
minute)
DC power with respect to sensor input and analog output:
50 V working (500 V for 1 minute)
7. CERTIFICATIONS AND COMPLIANCES:
SAFETY
UL Recognized Component, File #E156876, UL873, CSA 22.2
No. 24
Recognized to US and Canadian requirements under the
Component Recognition Program of Underwriters
Laboratories, Inc.
Type 4X Enclosure rating (Face only), UL50
IEC 1010-1, EN 61010-1: Safety requirements for electrical
equipment for measurement, control, and laboratory
use, Part I
IP65 Enclosure rating (Face only), IEC 529
ELECTROMAGNETIC COMPATIBILITY
Notes:
1
Self-recoverable loss of performance during EMI disturbance at
10 V/m:
Measurement input signal may deviate during EMI
disturbance.
For operation without loss of performance:
Install one ferrite core one turn, RLC #FCOR0000 or
equivalent, to I/O cables at unit.
2
Self-recoverable loss of performance during EMI disturbance at
10 Vrms:
Process and analog output signal may deviate during EMI
disturbance.
For operation without loss of performance:
Install one ferrite core one turn, RLC #FCOR0000 or
equivalent, to I/O cables and power cable at unit.
Refer to the EMC Installation Guidelines section of this
bulletin for additional information.
8. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: 0 to 50°C
Storage Temperature Range: -40 to 80°C
Operating and Storage Humidity: 85% max relative humidity
(non-condensing) from 0°C to 50°C
Altitude: Up to 2000 meters
9. CONNECTION: Wire-clamping screw terminals
10. CONSTRUCTION: Black plastic alloy case and collar style
panel latch. Panel latch can be installed for vertical or
horizontal instrument stacking. Black plastic textured bezel
with transparent display window. Controller meets NEMA
4X/IP65 requirements for indoor use when properly installed.
Installation Category II, Pollution Degree 2.
11. WEIGHT: 6.3 oz (179 g)
Enclosure class AEN 55011RF interference
Emissions to EN 50081-2
150 KHz - 80 MHz
Level 3; 10 V/rms
2
EN 61000-4-6RF conducted interference
Level 3; 2 kV power
Level 4; 2 kV I/OEN 61000-4-4Fast transients (burst)
80 MHz - 1 GHz
Level 3; 10 V/m
1
EN 61000-4-3Electromagnetic RF fields
Level 2; 4 kV contact
Level 3; 8 kV air
EN 61000-4-2Electrostatic discharge
Immunity to EN 50082-2
Power mains class A
