red lion PAX2D User Manual

21
LINE 1 DISPLAY COLOR
GrEEN rEd OrANGE
Select the desired color for the Line 1 Display and Units Mnemonic. The Line
1 display will actively change color as the selection is changed with the arrow
keys. This parameter can also be accessed in the Parameter Display Loop when
enabled. (see “Line 2 Display Access”)
DISPLAY INTENSITY LEVEL
1 to 4
Enter the desired Display Intensity Level (1-4) by using the arrow keys. The
display will actively dim or brighten as the levels are changed. This parameter
can also be accessed in the Parameter Display Loop when enabled.
DISPLAY CONTRAST LEVEL
0 to 15
Enter the desired Display Contrast Level (0-15) by using the arrow keys. The
display contrast / viewing angle will actively move up or down as the levels are
changed. This parameter can also be accessed in the Parameter Display Loop
when enabled.
LINE 1 DISPLAY VALUE SELECT/ENABLE
NO YES
Enter YES to select which values will be shown on the Line 1 display. A sub-
menu provides Yes/No selection for each available Line 1 value. Values set to
YES in the sub-menu will be displayed on Line 1.
DISPLAY DESCRIPTION FACTORY
Cnt A
Counter A
YES
Cnt b
Counter B
NO
Cnt C
Counter C
NO
RAtE A
Rate A
NO
RAtE b
Rate B
NO
RAtE C
Rate C
NO
Hi
Max Value
NO
Lo
Min Value
NO
LINE 1 DISPLAY SCROLL ENABLE/TIME
NO 1 to 15 seconds
If Line 1 Display Scrolling is desired, set the scroll time in seconds.
LINE 1 UNITS MNEMONIC(S)
OFF LAbEL CUSt FACt
Select the mode for Line 1 Units Mnemonic(s). See LINE 1 UNITS
MNEMONIC DIAGRAM for programming details.
SELECTION MODE DESCRIPTION
OFF
OFF No Line 1 mnemonic shown.
LAbEL
LABEL Single programmable mnemonic
shown for all Line 1 values.
CUSt
CUSTOM Custom programmable mnemonics
shown for each Line 1 value.
FACt
FACTORY Factory default mnemonics shown for
each Line 1 value.
The characters available for the programmable modes include:
A b C d E F G H I J K L M N O P Q R S t U V W Y Z
0 1 2 3 4 5 6 7 8 9 a c e g h i n o q r u - = [ ] / ° _ blank
Color
GrEEN
Ln1
d-LEV
4
dSP
d-Cont
7
dSP
SELECt
NO
Ln1
ScroLL
NO
Ln1
UNItS
FACt
Ln1
Color
GrEEN
Ln1
Line 1 Display
Color
d-LEV
4
dSP
Set Display
Intensity
SELECt
NO
Ln1
Select Line 1
Display Values
d-Cont
7
dSP
Set Display
Contrast
ScroLL
NO
Ln1
Line 1 Scroll
Enable/Time
UNItS
FACt
Ln1
Line 1 Units
Mnemonics
dISPLY
LINE 1
Selected Line 1 Color Displayed
P D
DISPLAY PARAMETERS (dISPLY)
LINE 1 PARAMETERS (LINE 1)
This section details programming for the Line 1 (Top Line) Display. The Counter values, Rate values and the Maximum (Hi) and Minimum (Lo) Rate Capture
values can be shown on the Line 1 display. The 3-digit Units mnemonic characters can be used to indicate which Line 1 display value is shown. Standard or custom
mnemonics are available for Line 1 values.
DISPLAY LINE SELECT
LINE 1 LINE 2
Select the Display Line to be programmed.
dISPLY
LINE 1
P
LINE 1 UNITS MNEMONIC DIAGRAM (3-DIGITS)
Edit
123
NO
P
Edit
Ln1
NO
P
123 = Current Units Mnemonic
P
UNItS
Ln1
OFF
dISPLY
LINE 1
UNItS
Ln1
LAbEL
Edit
123
YES
UNItS
Ln1
CUSt
UNItS
Ln1
FACt
Edit
123
Cnt A
Unit 1
123
1
Unit 2
123
2
Unit 3
123
3
Edit
123
Cnt b
Edit
123
Lo
P P
P
P
Unit 1
123
1
Unit 2
123
2
Unit 3
123
3
P P
P
P
P
P
Unit 1
123
1
Unit 2
123
2
Unit 3
123
3
P P
P
P
Unit 1
123
1
Unit 2
123
2
Unit 3
123
3
P P
P
P
(returns to currently selected value)
Additional Display Values:
(Count C, Rate A, Rate B, Rate C, Hi)
F1
F2
F1
F2
F1
F2
