Part List
No. PART NAME Q'TY No. PART NAME Q'TY
1 Main frame 1 41 Clip 2
2 Front stabilizer 1 42 Belt Drive Wheel 1
3 Rear Stabilizer 1 43 Flywheel 1
4 Front Post 1 44 Nylon Lock Nut M6 2
5 Left Lower Hand Rail 1 45 Adjust Screw Washer 2
6 Right Lower Hand Rail 1 46 Flat Washerφ10.5xφ25xT1.5 2
7 Left Foot Rail 1 47 Belt Adjust Screw M6x40 2
8 Right Foot Rail 1 48 Cross Crank 2
9 Left Upper Handle Bar 1 49 Screw φ4x15 8
10 Right Upper Handle Bar 1 50 Screw M6x20 4
11 Front Handle Bar 1 51 Disk 2
12 Computer 1 52 Flange Screw M8x20 2
13 Carriage Bolt M10 x 75L 4 53 Disk Cap 2
14 Domed Nut M10 4 54 Small Sleeve 4
15 Arc Washerφ10.5xφ25xT1.5 4 55 Big Sleeve 4
16 Round Head Bolt M8 x 15 4 56 Flat Stopper 2
17 Arc Washer φ8.5xφ22xT1.2 4 57 Flat Washer φ38xφ19xT2 2
17A Split Washer M8 4 58 Hex Bolt M8x25 2
18 Hex Head Bolt M10*80 2 59 Domed Nut M8 2
19 Flat Washer φ10.5xφ20xT1.5 4 60 Spacer 2
19A Flat Washer φ10.5xφ25xT1.5 2 61 Hand Pulse Sensor 2
20 Nylon Lock Nut M10 4 62 Screw M4x15 2
21 Sleeve Tube 2 63 Font Hand Grip 1
22 Domed Nut M10 2 64 Upper Hand Grip 2
23 Flat Washer φ19xφ31.8xT1.5 2 65 End Cover 2
24 Round Head Bolt M6x15 4 66 Main Cover Left 1
25 Carriage Bolt M6*φ8*25 4 67 Main Cover Right 1
26 Screw Φ5x15 12 68 Front Post Cover Left 1
27 Front End Cap with Wheel 2 69 Front Post Cover Right 1
28 Rear End Cap 2 70 Rear Cover 1
29 Middle Computer Wire 1 71 Screw φ5x15 22
30 Lower Computer Wire 1 72 U Type Nut 2
31 Hand Pulse Middle Wire 1 73 End Cap for Foot Tube 2
32 Hand Pulse Lower Wire 1 74L PVC Cap(L) 2
33 Computer Upper Wire 1 74R PVC Cap ® 2
34 Hand Pulse Upper Wire 1 75 Small Motor 2000 type 1
35 Adapter 6V 1 76 Magnet Control Cable 1
36 Foot Pad 2 77 Foot Pad Support 2
