Reed Instruments R8070SD - Manual Data Logging Mode; Automatic Data Logging Mode

14
Manual Data Logging Mode
In manual mode the LOGGER button is pressed to manually log a reading
on the inserted SD card at any time. In order to setup the meter for
manual data logging, follow steps 1 through 8 below.
1. Set the data logging sampling rate to '0' seconds.
2. Press the REC button to enter manual data logging mode.
 
number between 1 and 99).
4. Press the SET button to set the desired memory position.
5.
 and buttons to select one of the 99 data memory positions
in which to record.
6. Press the ENTER button to conrm the selection. Repeat steps 4 to
6 for every selection.
7. Press the LOGGER
will ash each time a data point is stored.
 REC button
2 seconds to resume normal operation.
Note: The meter will scan for a SD memory card when a rst manual
recording is attempted. If a card is not inserted or the card is defective,
the meter will ash CArD-E-. In this case, power the meter OFF and try
again with another SD memory card.
Automatic Data Logging Mode
In automatic mode the desired data logging sampling rate is set to 1, 2,
5, 10, 30, 60, 120, 300, 600, 1800 or 3600 seconds prior to recording.
In order to setup the meter for automatic data logging, follow steps 1
through 5 below.
1. Press the REC button and "REC" will appear on the LCD.
2. Press the LOGGER button to enter automatic data logging mode.
 
every time a reading is stored at the user selected sampling rate.
4. To pause the data logging session press the LOGGER button and
both the RECLOGGER buttons will stop ashing. To resume press
the LOGGER button again.
continued...
