INSTRUCTIONS CONCERNING CONNECTION CABLES.
➔ Wire size range: AWG 12...30, (solid/stranded) (UL).
➔ Use 60/75°C copper (Cu) conductor only.
➔ We recommend the use of separate power supplies for the safety
module and for other electrical power equipment (electric motors,
inverters, frequency converters) or other sources of disturbance.
➔ Cables used for connections of longer than 50m must have a cross-
section of at least 1mm2 (AWG16).
➔ Use Ethernet cable Cat. 5 or higher for network connections.
MOSAIC M1S COM module
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
NC
-
-
-
3
NC
-
-
-
4
0VDC
-
0VDC power supply
-
5
OSSD1
Output
Solid State Safety Output 1
PNP active high
6
OSSD2
Output
Solid State Safety Output 2
PNP active high
7
RESTART_FBK1/
STATUS1
Input/
Output
Feedback/Restart 1
Input according to EN 61131-2
Programmable signal output
PNP active high
8
RESTART_FBK2/
STATUS2
Input/
Output
Feedback/Restart 2
Input according to EN 61131-2
Programmable signal output
PNP active high
9
OSSD3
Output
Solid State Safety Output 3
PNP active high
10
OSSD4
Output
Solid State Safety Output 4
PNP active high
11
RESTART_FBK3/
STATUS3
Input/
Output
Feedback/Restart 3
Input according to EN 61131-2
Programmable signal output
PNP active high
12
RESTART_FBK4/
STATUS4
Input/
Output
Feedback/Restart 4
Input according to EN 61131-2
Programmable signal output
PNP active high
13
OUT_TEST1
Output
Short circuit detected output
PNP active high
14
OUT_TEST2
Output
Short circuit detected output
PNP active high
15
OUT_TEST3
Output
Short circuit detected output
PNP active high
16
OUT_TEST4
Output
Short circuit detected output
PNP active high
17
INPUT1
Input
Digital input 1
Input according to EN 61131-2
18
INPUT2
Input
Digital input 2
Input according to EN 61131-2
19
INPUT3
Input
Digital input 3
Input according to EN 61131-2
20
INPUT4
Input
Digital input 4
Input according to EN 61131-2
21
INPUT5
Input
Digital input 5
Input according to EN 61131-2
22
INPUT6
Input
Digital input 6
Input according to EN 61131-2
23
INPUT7
Input
Digital input 7
Input according to EN 61131-2
24
INPUT8
Input
Digital input 8
Input according to EN 61131-2
