Reer MOSAIC M1S COM Master Module User Manual

18 8541468 • 15/12/2021 • Rev.0
MOSAIC M1S COM - MASTER MODULE
English
TECHNICAL FEATURES
PARAMETER
VALUE
Rated voltage
24VDC  20%
Dissipated power
4W max
Digital INPUTS
(No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART
(No./description)
4 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT
(No./description)
4 / to check for short-circuits - overloads
Signaling OUTPUTS
(No./description)
4 / programmable - PNP active high
OSSD (No./description)
4 single outputs (or 2 dual channel outputs), cat. 4
400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
Network connectors
(No./description)
2 / RJ45 for fieldbus and/or remote connection
remote connection. Cable cat.5 or higher
Network connection
Speed 10/100 Mbit - RSA encrypted authentication
and AES 128 bit encrypted communication
TCP port = 300
Available fieldbuses
▪ Ethernet/IP
▪ Modbus TCP
▪ Profinet
▪ EtherCAT
Default = Ethernet/IP in DHCP
Slot for MCM card
Available
Connection to PC
USB 2.0 type C connector - Max cable length: 3m
Connection to slave units
via MSC 5-way ReeR proprietary bus
 Precise, complete compliance with all standards, instructions and
warnings in MOSAIC handbook is essential for the correct operation of
MOSAIC controller.
 ReeR therefore declines any responsibility for all and anything resulting
from failure to comply with all or some of the aforesaid instructions.
The MSD software and manuals are available at URL: https://www.reersafety.com/download
