OSSD
The OSSD (static semiconductor safety outputs) are short circuit protected.
They supply:
• in the ON condition: Uv-0,75V...Uv (where Uv is 24V ± 20%)
• in the OFF condition: 0V...2V r.m.s.
The maximum load of 400mA@24V corresponds to a minimum resistive
load of 60. The maximum capacitive load is 0.82F. The maximum
inductive load is 2mH.
Different output configurations (configurable with MSD configuration
software) can be set:
• 4 single channels (1 Safety Output per channel with its relative
feedback input).
• 2 dual channels (2 Safety Outputs per channel with their relative
feedback input).
• 1 dual channel and 2 single channels.
CHECKLIST AFTER INSTALLATION
The MOSAIC system is able to detect the faults that occurs in each own
module.
Anyway to have the system perfect operation perform the following checks
at start up and at least every one year:
5. Operate a complete system TEST
(see "TESTING the system", in the MOSAIC instruction manual
available on the ReeR website)
