Reer MOSAIC MO2 User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
36 8540780 • 07/05/2018 • Rev.33
English
MR2 - MR4 modules

MR2 – MR4: TECHNICAL DATA CONCERNING SAFETY
FEEDBACK CONTACT PRESENT
FEEDBACK CONTACT MISSING
PFHd
SFF
MTTFd
DCavg
PFHd
SFF
MTTFd
DCavg
3,09E-10
99,6%
2335,94
98,9%
tcycle1
DC13 (2A)
9,46E-10
60%
2335,93
0
tcycle1
DC13 (2A)
8,53E-11
99,7%
24453,47
97,7%
tcycle2
1,08E-10
87%
24453,47
0
tcycle2
6,63E-11
99,8%
126678,49
92,5%
tcycle3
6,75E-11
97%
126678,5
0
tcycle3
8,23E-09
99,5%
70,99
99,0%
tcycle1
AC15 (3A)
4,60E-07
50%
70,99
0
tcycle1
AC15 (3A)
7,42E-10
99,5%
848,16
99,0%
tcycle2
4,49E-09
54%
848,15
0
tcycle2
1,07E-10
99,7%
12653,85
98,4%
tcycle3
1,61E-10
79%
12653,85
0
tcycle3
3,32E-09
99,5%
177,38
99,0%
tcycle1
AC15 (1A)
7,75E-08
51%
177,37
0
tcycle1
AC15 (1A)
3,36E-10
99,6%
2105,14
98,9%
tcycle2
1,09E-09
60%
2105,14
0
tcycle2
8,19E-11
99,7%
28549,13
97,5%
tcycle3
1,00E-10
88%
28549,13
0
tcycle3
tcycle1: 300s (1 commutation every 5 minutes)
tcycle2: 3600s (1 commutation every hour)
tcycle3: 1 commutation every day
MOR4 – MOR4S8 module
