1 Product Specifications
Table 1 Product Specifications
Model No.
XT4
Dimensions
(Nominal)
Width 1
2110 mm
Width 2
2110 mm
Height
2180 mm
Weight
Maximum Gross Mass
1000 kg
Tare Weight
500 kg
Payload
500 kg
Materials
Frame
316 Stainless steel, A4 stainless fixings
Central Column / Load
Plate
316 Stainless/ Duplex Stainless
Steel Components
All stainless except for floor grating
Buoyancy
PE moulded shell with Polyurethane (PU)
closed cell foam fill.
Seat Base/ Seat Back
Polyolefin shell filled with polystyrene
closed cell balls
Landing Feet
EVA Foam
Operating
Temperatures
Standard Model
-20°C to +50°C
Arctic Model
-40°C to +50°C
Suspension
Springs
2 x Coated heavy duty coil spring
Dampers
2 x Stainless steel 400mm recoil dampers
Seating
Seats
4 x Full Height Seats
Harnesses
3 Point, Quick Release Buckle
Grab Handles
2 Per Passenger
Lifting Points SWL
Main
1000 kg
Backup
1000 kg
Handling
1000 kg
Wire Rope Lifting
Assembly
Safe Working Load
1240 kg
Wire Rope
Anti-rotation wire rope
Number of
Passengers
Standard
4
Stretcher Mode
1 + Stretcher
Luggage Capacity
Light Luggage
Accessory available on request
Large Luggage Tray
Accessory available on request
Impact Protection
Vertical impacts
4.5 m/s
Lateral impacts
2 m/s
Stability
Horizontal
35°, for a load of 1-4 passengers.
Self-Righting
Up to 180˚ inverted to the vertical position
Certification
Class
Attestation of Conformity Certificate No.
MAC0000002 i01
Quality
System
Manufactured to ISO 9001:2008
Standards
National Technical
Standards
UK, BS EN 1993 series: The Use of
Structural Steel in Building.
Industry European
Standards
EC Machinery Directive
EN 14121-1, BS EN 12100-10
Load Test – ILO152 / LOLER
National Regulations
UK, PUWER / LOLER
