6 Replacement Parts
6.1 Introduction
Replacement parts can be supplied as individual items or as appropriate kits. Prior to
ordering any replacement parts or kits, establish the serial number which is stamped on the
data plate. The serial number is XT6- XXX where XXX represents a three digit number.
Reflex Marine holds replacement parts and accessories in stock. We are able to supply most
individual components. A full list of parts is contained in the customer drawing pack, which
is issued with every unit.
It may be advisable to hold an inventory of frequently replaced parts. This will help to
ensure the continued safe operation of the carrier. Minimum stock quantities shall be
influenced by:
i. Remoteness of location
ii. Downtime implications
iii. Criticality of maintaining crew and emergency response (Medevac) access.
iv. Usage
v. Customs processing time
vi. Delivery cost for small parts
Reflex Marine can recommend stock items and quantities for your operation.
It is recommended that only genuine OEM parts (including lifting assemblies) are
used.
6.2 Kits
The following kits are available for routine and non-routine maintenance. Ordering an
appropriate kit is more economical than replacing individual parts.
Kit Name
Part Number
Contents
Lifting Assembly Kit
RA0116
Wire Rope Lifting Assembly
Lifting Assembly Cover
Associated Fixings
Replacement Parts Kit
RA0117
Critical Parts Minus The Wire Rope
Lifting Assembly
Critical Part Kit
RA0090
Critical Parts
Harness Kit
RA0295
6 X Harnesses plus
Associated Fixings
Landing Foot Kit
RA0303
4 X Feet plus
Associated Fixings
Full Service Kit
RA0293
1x Lifting Assembly Kit
1 X Replacement Parts Kit
1 X Harness Kit
1 X Landing Foot Kit
1 x Suspension Kit
Suspension Kit
RA0294
4 X Springs
2 X Recoil Dampers
Associated Fixings
