Reflex Marine FROG-XT6 - Product Specifications

Rev 0.2 4 | P a g e
1 Product Specifications
Table 1 Product Specifications
Model No.
XT6
Dimensions
(Nominal)
Width 1
2110 mm
Width 2 (Across Buoyancy)
2660 mm
Height
2180 mm
Weight
Maximum Gross Mass
1200 kg
Tare Weight
540 kg
Payload - SWL
660 kg
Materials
Frame
316 stainless steel, A4 stainless fixings
Central Column / Load Plate
316 duplex stainless
Other Steel Components
All stainless except for floor grating
Buoyancy
Polyethylene (PE) moulded shell with
polyurethane (PU) closed cell foam fill.
Seat Base/ Seat Back
Polyolefin shell filled with polystyrene
closed cell
Landing Feet
EVA closed cell foam
Operating
Temperatures
Standard Model
-20°C to +50°C
Arctic Model
-40°C to +50°C
Suspension
Springs
4 x stainless steel heavy duty coil spring
Dampers
2 x stainless steel 400mm recoil dampers
Seating
Seats
6 x full height seats
Harnesses
3 point, quick release buckle
Grab Handles
8
Lifting Points
SWL
Main
1200 kg (man-riding)
Backup
1200 kg (man-riding)
Handling
1200 kg
Wire Rope
Lifting
Assembly
Safe Working Load
1200 kg
Wire Rope
Anti-rotation wire rope
Number of
Passengers
Standard
6
Stretcher Mode
1 + stretcher
Luggage
Capacity
Light Luggage
Accessory available on request
Large Luggage Tray
Accessory available on request
Impact
Protection
Vertical impacts
Passengers are protected during heavy
landings at speeds of up to 4.5 m/s
Lateral impacts
Passengers are protected from lateral
impacts at speeds of up to 2 m/s
Stability
Horizontal
35°, for a load of 1-6 passengers
Submerged Self-Righting
Up to 180˚ inverted to the vertical position
Type Approval
Class
EC Type examination certificate No.
MAC000005 i01
Quality
System
Manufactured to ISO 9001:2008
Standards
National Technical Standards
UK, BS EN 1993 series: ‘The Use of
Structural Steel in Building’
Industry European Standards
EC Machinery Directive
EN 14121-1, BS EN 12100-10
Load Test – ILO152 / LOLER
National Regulations
UK, PUWER / LOLER
